TKV
Boilers for industrial systems
TKV
Hot-water boiler on solid fuel, type TKV
This type of boiler is intented for heating larger units, and it is produced in the power range from 100kW to 2000kW in variants with or without ventilators. Boiler type TKV is recommended for installation in boiler rooms where natural draft of chimneys is not enough for quality combustion.
Download the instructions
Silence at work
Compact dimensions
Sustainable energy
Energetic efficiency
Cost savings
Ecologically aware
Dimensions
A: 950mm B: 1490mm C: 1685mm
D: 230mm E: 300 H: 1395
Weight
704 kg
Furnace power
100 kW
Amount of water
358 l
Dimensions
A: 910mm B: 1680mm C: 1870mm
D: 250mm E: 320 H: 1530
Weight
940 kg
Furnace power
150 kW
Amount of water
640 l
Dimensions
A: 1080mm B: 1740mm C: 1980mm
D: 300mm E: 320 H: 1570
Weight
1170 kg
Furnace power
200 kW
Amount of water
848 l
Do You need help for some of our products? Service center will answer on all of Your questions in 24 hours.
Contact service centerAll informations and specifications of all products You can see in Topling catalog.
Donwload PDF
